Metal-Oxide-Varistor TVR05470
Illustration_TVR-Series

Metal-Oxide-Varistor TVR05470

Product No.:
TVR05470
Description
Metal-Oxide-Varistor TVR05470
Varistor Voltage (@ 1mA DC): 47 (42~52) V
Max. Continuous Voltage: 30 VAC / 38 VDC
Max. Clamping Voltage (8/20μs): 104 V / 1.0 A
Max. Surge Current (8/20μs): 100 A
Rated Power: 0.01 W
Max. Energy (10/1000μs): 1.1 J
Diameter: 5mm
Downloads
Download Datasheet
