Überspannungsschutz

Suppressordioden, Metalloxid-Varistoren und Gasableiter gehören zu den Komponenten welche Alpha Therm für den zuverlässigen Überspannungsschutz anbietet.

Metall-Oxid-Varistor TVR05271

Metal-Oxide-Varistor TVR05271
Varistor Voltage (@ 1mA DC): 270 (243~297) V

Max. Continuous Voltage: 175 VAC / 225 VDC

Max. Clamping Voltage (8/20μs): 475 V / 5.0 A

Max. Surge Current (8/20μs): 400 A

Rated Power: 0.1 W

Max. Energy (10/1000μs): 8.5 J

Diameter: 5mm

Preis auf Anfrage

Metall-Oxid-Varistor TVR05301

Metal-Oxide-Varistor TVR05301
Varistor Voltage (@ 1mA DC): 300 (270~330) V

Max. Continuous Voltage: 195 VAC / 250 VDC

Max. Clamping Voltage (8/20μs): 525 V / 5.0 A

Max. Surge Current (8/20μs): 400 A

Rated Power: 0.1 W

Max. Energy (10/1000μs): 8.5 J

Diameter: 5mm

Preis auf Anfrage

Metall-Oxid-Varistor TVR05331

Metal-Oxide-Varistor TVR05331
Varistor Voltage (@ 1mA DC): 330 (297~363) V

Max. Continuous Voltage: 215 VAC / 275 VDC

Max. Clamping Voltage (8/20μs): 585 V / 5.0 A

Max. Surge Current (8/20μs): 400 A

Rated Power: 0.1 W

Max. Energy (10/1000μs): 9.2 J

Diameter: 5mm

Preis auf Anfrage

Metall-Oxid-Varistor TVR05361

Metal-Oxide-Varistor TVR05361
Varistor Voltage (@ 1mA DC): 360 (324~396) V

Max. Continuous Voltage: 230 VAC / 300 VDC

Max. Clamping Voltage (8/20μs): 620 V / 5.0 A

Max. Surge Current (8/20μs): 400 A

Rated Power: 0.1 W

Max. Energy (10/1000μs): 10 J

Diameter: 5mm

Preis auf Anfrage

Metall-Oxid-Varistor TVR05391

Metal-Oxide-Varistor TVR05391
Varistor Voltage (@ 1mA DC): 390 (351~429) V

Max. Continuous Voltage: 250 VAC / 320 VDC

Max. Clamping Voltage (8/20μs): 675 V / 5.0 A

Max. Surge Current (8/20μs): 400 A

Rated Power: 0.1 W

Max. Energy (10/1000μs): 12 J

Diameter: 5mm

Preis auf Anfrage

Metall-Oxid-Varistor TVR05431

Metal-Oxide-Varistor TVR05431
Varistor Voltage (@ 1mA DC): 430 (387~473) V

Max. Continuous Voltage: 275 VAC / 350 VDC

Max. Clamping Voltage (8/20μs): 745 V / 5.0 A

Max. Surge Current (8/20μs): 400 A

Rated Power: 0.1 W

Max. Energy (10/1000μs): 13 J

Diameter: 5mm

Preis auf Anfrage

Metall-Oxid-Varistor TVR05471

Metal-Oxide-Varistor TVR05471
Varistor Voltage (@ 1mA DC): 470 (423~517) V

Max. Continuous Voltage: 300 VAC / 385 VDC

Max. Clamping Voltage (8/20μs): 810 V / 5.0 A

Max. Surge Current (8/20μs): 400 A

Rated Power: 0.1 W

Max. Energy (10/1000μs): 15 J

Diameter: 5mm

Preis auf Anfrage

Metall-Oxid-Varistor TVR05511

Metal-Oxide-Varistor TVR05511
Varistor Voltage (@ 1mA DC): 510 (459~561) V

Max. Continuous Voltage: 320 VAC / 410 VDC

Max. Clamping Voltage (8/20μs): 878 V / 5.0 A

Max. Surge Current (8/20μs): 400 A

Rated Power: 0.1 W

Max. Energy (10/1000μs): 16 J

Diameter: 5mm

Preis auf Anfrage

17 bis 24 (von insgesamt 33)
