Überspannungsschutz

Suppressordioden, Metalloxid-Varistoren und Gasableiter gehören zu den Komponenten welche Alpha Therm für den zuverlässigen Überspannungsschutz anbietet.
Metall-Oxid-Varistor TVR05561
Metall-Oxid-Varistor TVR05561
Metal-Oxide-Varistor TVR05561
Varistor Voltage (@ 1mA DC): 560 (504~616) V
Max. Continuous Voltage: 350 VAC / 450 VDC
Max. Clamping Voltage (8/20μs): 962 V / 5.0 A
Max. Surge Current (8/20μs): 400 A
Rated Power: 0.1 W
Max. Energy (10/1000μs): 18 J
Diameter: 5mm
Preis auf Anfrage
Metall-Oxid-Varistor TVR05621
Metall-Oxid-Varistor TVR05621
Metal-Oxide-Varistor TVR05621
Varistor Voltage (@ 1mA DC): 620 (558~682) V
Max. Continuous Voltage: 395 VAC / 510 VDC
Max. Clamping Voltage (8/20μs): 1050 V / 5.0 A
Max. Surge Current (8/20μs): 400 A
Rated Power: 0.1 W
Max. Energy (10/1000μs): 18 J
Diameter: 5mm
Preis auf Anfrage
Metall-Oxid-Varistor TVR05681
Metall-Oxid-Varistor TVR05681
Metal-Oxide-Varistor TVR05681
Varistor Voltage (@ 1mA DC): 680 (612~748) V
Max. Continuous Voltage: 420 VAC / 560 VDC
Max. Clamping Voltage (8/20μs): 1120 V / 5.0 A
Max. Surge Current (8/20μs): 400 A
Rated Power: 0.1 W
Max. Energy (10/1000μs): 18 J
Diameter: 5mm
Preis auf Anfrage
Metall-Oxid-Varistor TVR05751
Metall-Oxid-Varistor TVR05751
Metal-Oxide-Varistor TVR05751
Varistor Voltage (@ 1mA DC): 750 (675~825) V
Max. Continuous Voltage: 465 VAC / 615 VDC
Max. Clamping Voltage (8/20μs): 1240 V / 5.0 A
Max. Surge Current (8/20μs): 400 A
Rated Power: 0.1 W
Max. Energy (10/1000μs): 18 J
Diameter: 5mm
Preis auf Anfrage
Metall-Oxid-Varistor TVR07180
Metall-Oxid-Varistor TVR07180
Metal-Oxide-Varistor TVR07180
Varistor Voltage (@ 1mA DC): 18 (16~20) V
Max. Continuous Voltage: 11 VAC / 14 VDC
Max. Clamping Voltage (8/20μs): 36 V / 2.5 A
Max. Surge Current (8/20μs): 250 A
Rated Power: 0.02 W
Max. Energy (10/1000μs): 0.9 J
Diameter: 7mm
Preis auf Anfrage
Metall-Oxid-Varistor TVR07220
Metall-Oxid-Varistor TVR07220
Metal-Oxide-Varistor TVR07220
Varistor Voltage (@ 1mA DC): 22 (20~24) V
Max. Continuous Voltage: 14 VAC / 18 VDC
Max. Clamping Voltage (8/20μs): 43 V / 2.5 A
Max. Surge Current (8/20μs): 250 A
Rated Power: 0.02 W
Max. Energy (10/1000μs): 1.1 J
Diameter: 7mm
Preis auf Anfrage
Metall-Oxid-Varistor TVR07270
Metall-Oxid-Varistor TVR07270
Metal-Oxide-Varistor TVR07270
Varistor Voltage (@ 1mA DC): 27 (24~30) V
Max. Continuous Voltage: 17 VAC / 22 VDC
Max. Clamping Voltage (8/20μs): 53 V / 2.5 A
Max. Surge Current (8/20μs): 250 A
Rated Power: 0.02 W
Max. Energy (10/1000μs): 1.4 J
Diameter: 7mm
Preis auf Anfrage
SD25T600L312PV
SD25T600L312PV
SD25T600L312PV
Überspannungsschutzgerät für PV
Nennspannung Un: 600 VDC
Max. Dauerspannung Ucpv: 660 VDC
Nennableitstrom In (8/20us): 25kA
Max. Ableitstrom Imax (8/20us): 50kA
Impuls-Ableitstrom Iimp (10/350us): 12.5kA
Spannungsschutzbewertung Up: 3.0kV
Schutzmodus: Y
SPD nach EN 61643-11:
Typ 1 + Typ 2
Staffelpreise:
1-19 Stück je 57,52 EUR
20-49 Stück je 51,82 EUR
50-99 Stück je 47,76 EUR
> 99 Stück je 46,27 EUR
57,52 EUR
zzgl. 19% MwSt. zzgl. Versand
Stück:

25 bis 32 (von insgesamt 36)
